450 m at 50% reflectivity, 0 klx 250 m at 10% reflectivity, 100 klx
Point Rate
Single return: 240,000 fps max. Multiple returns: 1,200,000 fps max.
System Accuracy
Horizontal: 5 cm at 150 m Vertical: 4 cm at 150 m
Point Cloud
Coloring by elevation, Coloring by reflectivity, True color
Ins
IMU update Frequency
200 Hz
Accelorometer Range
± 6 g
Angular Velocity Meter Range
± 300 dps
Yaw Accuracy
Real time: 0.2°, post-processing: 0.05°.
Pitch / Roll Accuracy
Real time: 0.05°, post-processing: 0.025°.
Data Storage
Raw Data Storage
Photo/IMU/Point cloud data storage
Point Cloud Data Storage
Real-time modeling data storage
Supported microSD Cards
microSD: Class 10 or UHS-1 rating or above; Max capacity: 256 GB
Post-processing Software
Supported Software
DJI Terra
Data format
DJI Terra supports exporting standard format point cloud models: Data Format Point cloud format: PNTS/LAS/PLY/PCD/S3MB format Reconstruction model format: B3DM/OSGB/PLY/OBJ/S3MB format
